Smart Vent 1540-511 Gray Dual Function Double Stacker Block Wall 16" x 16" Flood Vent

- Brand
- Smart Vent
- SKU:
- 1540-511-GRY
- Availability:
- Special Order Item, Ships Within 3 to 4 Business Days
- Shipping:
- Calculated at Checkout
- Model:
- 1540-511-GRY
- Installation Type:
- Masonry Wall
- Style:
- Dual Function
- Certified For:
- 400 sqft Flood Coverage, 102 sqin Air Ventilation
- Dimensions:
- 16"W x 16"H x 3"D
- Finish:
- Gray Powder Coated 316 Stainless Steel
Application
These vents are used for a home with a crawlspace or any enclosed area that desires natural air ventilation and flood protection.
Flood Protection
The vent door is latched closed until it comes in contact with flood water. Entering flood water lifts the patented internal floats which unlatch and allow the door to rotate open. This allows the flood water to automatically enter and exit through the frame opening, relieving the pressure from the foundation walls. Certified flood debris clearance is demonstrated with a 3” diameter opening when the flood door is activated.
Ventilation
A bimetal coil automatically opens and closes the ventilation louvers as temperature changes. No electricity is required. The louvers will be fully closed at 35F and fully open at 75F. In the event of a flood the internal floats lift to release the flood door to rotate open and relieve the hydrostatic pressure regardless of the louvers’ position, open or closed.
